Product Parameters GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. The power amplifier uses domestic core key components and can operate normally at temperatures of -10~+55°C. This document stipulates the radio frequency and monitoring technical indicators of the 600-700MHz 50W power amplifier module,

Product Parameters --GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. --The power amplifier uses domestic core key components and can operate normally at temperatures of -10~+55°C. --This document stipulates the radio frequency and monitoring technical indicators of the 910-1050MHz 50W power amplifier

Product Description Specification item Technical parameters Working frequency 840-930MHz Saturated output power 47±1dBm @input=3~5dbm Gain 45±2dB In-band fluctuation ≤2.0dB Out-of-band spurious 9kHz～1GHz:≤-36dBm/30kHz 1GHz～12.75GHz:≤-30dBm/30KHz Input VSWR/Out VSWR ≤2 Gain temperature stability ≤±1.5dB Working voltage DC+32V Temperature Protection(warn) Temperature protection 90 degrees(See PIN8) VSWR Protection(warn) Reverse Power 15W protection Working current ≤4A Power

Product overview 2.4G 2400-2486Mhz module anti-drone module Power and Frequnecy support Customzation form 380MHZ- 5.8g, 10W,20W,30W, 40W, 50w,100W --The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the modul Parameters Frequency 2.4G Gain 47dBm Size 125*60*20mm Power 50W Power Flatness 1-1.5dB Supply Current 2.1A Operating Temperature --10~+55ºC RF Connector

Product overview 433Mhz 428-438Mhz 100W anti-drone gan module Power and Frequnecy support Customzation form 380MHZ- 5.8g, 10W,20W,30W, 40W, 50w,100W --The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the modul Parameters Frequency 433Mhz 428-438Mhz Gain 50dBm Size 170*94*26.5mm (excluding connectors) Power 100W Weight 1.5kg Voltage 30Vdc Range: 24-36V Intra

Temperature and VSWR Protection 860-960Mhz 100W RF Amplifier Module for FPV Autel Dji Equipment Product Description Specification Frequency 860-960mhz Power supply 100W Saturated output power 50±1dBm @input=5dbm Gain 50±2dB In-band fluctuation ≤2.0dB Out-of-band spurious 9kHz～1GHz:≤-36dBm/30kHz 1GHz～12.75GHz:≤-30dBm/30KHz Input VSWR/Out VSWR ≤2 Gain temperature stability ≤±1.5dB Working voltage DC+32V Protection Temperature protection 90 degrees,Reverse Power 30W protection

Product Description Specification Frequency 960-1100mhz Power supply 100W Saturated output power 50±1dBm @input=5dbm Gain 50±2dB In-band fluctuation ≤2.0dB Out-of-band spurious 9kHz～1GHz:≤-36dBm/30kHz 1GHz～12.75GHz:≤-30dBm/30KHz Input VSWR/Out VSWR ≤2 Gain temperature stability ≤±1.5dB Working voltage DC+32V Protection Temperature protection 90 degrees,Reverse Power 30W protection Working current ≤8.5A Power supply monitoring interface Power supply: 7W2 power seat A1:32V A2

Product Description Specification Frequency 710-760mhz Power supply 100W Saturated output power 50±1dBm @input=5dbm Gain 50±2dB In-band fluctuation ≤2.0dB Out-of-band spurious 9kHz～1GHz:≤-36dBm/30kHz 1GHz～12.75GHz:≤-30dBm/30KHz Input VSWR/Out VSWR ≤2 Gain temperature stability ≤±1.5dB Working voltage DC+32V Protection Temperature protection 90 degrees,Reverse Power 30W protection Working current ≤8.5A Power supply monitoring interface Power supply: 7W2 power seat A1:32V A2

Product Description Lead time Quantity(PCS)
